G209 BOW TYPE SHACKLE

US Type Screw Pin Anchor Shackle G209美式弓形模锻卸扣G209* Meet the requirement of Federal Specification RR-C-271 D Type IVA, Grade A, Class 2.* Drop Forged, Quenched and Tempered.* Max Proof Load is 2.2 Times

About Products

US Type Screw Pin Anchor Shackle G209
美式弓形模锻卸扣G209

* Meet the requirement of Federal Specification RR-C-271 D Type IVA, Grade A, Class 2.
* Drop Forged, Quenched and Tempered.
* Max Proof Load is 2.2 Times the WLL, Min Break Strength is 6 Times the WLL.
Nominal
Size
(in.) 		WLL

(ton) 		A B C D E F G H L M P Weight
(in) (in) (in) (in) (in) (in) (in) (in) (in) (in) (in) (lbs)
3/16 1/3 0.38 0.25 0.88 0.19 0.6 0.56 0.98 1.47 0.16 1.12 0.19 0.05
1/4 1/2 0.47 0.31 1.13 0.25 0.78 0.61 1.28 1.84 0.19 1.38 0.25 0.12
5/16 3/4 0.53 0.38 1.22 0.31 0.84 0.75 1.47 2.09 0.22 1.66 0.31 0.19
3/8 1 0.66 0.44 1.44 0.38 1.03 0.91 1.78 2.49 0.25 2.03 0.38 0.31
7/16 1-1/2 0.75 0.5 1.69 0.44 1.16 1.06 2.03 2.91 0.31 2.38 0.44 0.38
1/2 2 0.81 0.63 1.88 0.5 1.31 1.19 2.31 3.28 0.38 2.69 0.5 0.63
5/8 3-1/4 1.06 0.75 2.38 0.63 1.69 1.5 2.94 4.19 0.44 3.34 0.69 1.38
3/4 4-3/4 1.25 0.88 2.81 0.75 2 1.81 3.5 4.97 0.5 3.97 0.81 2.25
7/8 6-1/2 1.44 1 3.31 0.88 2.28 2.09 4.03 5.83 0.5 4.5 0.97 3.38
1 8-1/2 1.69 1.13 3.75 1 2.69 2.38 4.69 6.56 0.56 5.07 1.06 5.32
1-1/8 9-1/2 1.81 1.25 4.25 1.16 2.91 2.69 5.16 7.47 0.63 5.59 1.25 6.81
1-1/4 12 2.03 1.38 4.69 1.29 3.25 3 5.75 8.25 0.69 6.16 1.38 9.5
1-3/8 13-1/2 2.25 1.5 5.25 1.42 3.63 3.31 6.38 9.16 0.75 6.84 1.5 13.25
1-1/2 17 2.38 1.63 5.75 1.54 3.88 3.63 6.88 10 0.81 7.35 1.62 17.2
1-3/4 25 2.88 2 7 1.84 5 4.19 8.86 12.34 1 9.08 2.25 30.38
2 35 3.25 2.25 7.75 2.08 5.75 4.81 9.97 13.68 1.22 10.34 2.4 45
2-1/2 55 4.13 2.75 10.5 2.71 7.25 5.69 12.87 17.84 1.38 13 3.13 85.75
